TP-Link RE650 Wireless-AC2600 Range Extender

Web ID: 21323

Superior Extended Range Four fixed external antennas extend Wi-Fi coverage by up to 14,000 sq. ft. 4-Stream for AC2600 Dual Band Wi-Fi Simultaneous 800Mbps on 2.4GHz + 1733Mbps on 5GHz 44 MU-MIMO Simultaneously transfers data to multiple devices for 4x faster performance Beamforming Technology Send targeted Wi-Fi signal to individual devices for stronger connections
Manufacturer Warranty: 3 Year
Manufacturer PN: RE650
GTIN: 6935364099411
Manufacturer Website

$169

Blazing-Fast Dual Band Wi-Fi Extension

With four external and dual band antennas, the RE650 establishes a stable wireless connection to any Wi-Fi router and boost the network's coverage by up to 14,000 square feet*. The 880MHz dual-core processor provides maximum Wi-Fi performance, keeping your smartphones and tablets connected as you move throughout your home.
Beamforming technology detects the location of devices and concentrates Wi-Fi towards them for stronger connections.



*Maximum extended Wi-Fi coverage specification is based on performance test results. Actual Wi-Fi coverage may vary due to different environment, building material and wireless interferences.

4-Stream AC2600 Dual Band Wi-Fi

Using 4-Stream technology to boost its Wi-Fi capability, the RE650 reaches industry-leading maximum speeds of up to 800Mbps on 2.4GHz, 1733Mbps on 5GHz. This provides the speed and elite performance necessary to support your most demanding online applications, including simultaneous 4K streaming and lag-free gaming.



More Connections and Faster for Everyone

MU-MIMO technology allows the RE650 to serve up to four devices at once, reducing wait time and greatly increasing Wi-Fi throughput for every device. With MU-MIMO, the RE650 runs up to 4x faster than traditional AC range extender.





Traditional RE

Sends data to one device at a time




MU-MIMO RE650

Simultaneously sends data to multiple devices

High-speed Gigabit Wired Connection

The RE650’s Gigabit Ethernet port lets you connect a wired device such as a game console or smart TV to create a fast, reliable wired connection.



Find the Best Spot with
Intelligent Signal Indicator

The Intelligent Signal Light helps you quickly find the
best location to install the RE650.

  • Blue

    Good connection

  • Red

    Too far away from the router



Built-in Access Point Mode

RE650 is more than a wireless range extender. Simply plug an Ethernet cable into its Ethernet port, and easily turn your wired internet connection into a 4×4 MU-MIMO dual band wireless access point.




Drop-Free and Seamless Dual Band Connections

If one of the main router's dual bands drops suddenly, or in case the main router can only deliver single band, the RE650 still provides stable dual-band connections for clients, allowing you to enjoy stable and drop-free experience on all your devices.



  • Traditional RE

  • Main Router

  • RE650

Easy Monitoring and Control

TP-Link Tether is an intuitive app that allows users to conveniently monitor the state of your range extender, controlling its functions and altering its settings from any compatible mobile device.

Plug Type EU, UK, US
Standards and Protocols IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Interface 1 x 10/100/1000M Ethernet Port (RJ45)
Button WPS Button, Reset Button, LED Button, Power Button
Power Consumption 12W(max power consumption)
Antenna 4 x external
Dimensions ( W x D x H ) 6.4 x 3.4 x 1.6 in. (163 x 86 x 40mm)
WIRELESS FEATURES
Frequency 2.4GHz & 5GHz(11ac)
Signal Rate 5GHz:Up to 1733Mbps
2.4GHz:Up to 800Mpbs
Reception Sensitivity 5GHz:
11a 6Mbps:-96dBm@10% PER
11a 54Mbps: -78dBm@10% PER
11ac HT20 mcs8: -69dBm@10% PER
11ac HT40 mcs9: -66dBm@10% PER
11ac HT80 mcs9: -63dBm@10% PER
2.4GHz
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER
Wireless Modes Range Extender/Access Point
Wireless Functions Wireless Statistic
Concurrent Mode boost both 2.4G/5G WiFi band
Access Control
LED Control
Domain Login Function
Wireless Security 64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power <20dBm(2.4GHz)
<23dBm(5GHz)
OTHERS
Certification CE, FCC, RoHS
Package Contents AC2600 Wi-Fi Range Extender RE650
Quick Installation Guide
Box Dimensions (W X D X H) 7.9 x 4.9 x 3.8 in. (202 x 125 x 97mm)
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
Environment Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
