12 x M.2 NVMe Slot Asustor FLASHTOR 12 Pro Gen2 10Gb NAS Unit

Web ID: 45305

  • AMD Quad-Core 6 nm Ryzen Embedded V3C14 Processor
  • Twelve M.2 slots for NVMe SSDs Supports up to PCIe 4.0 x4
  • Dual 10-Gigabit Ethernet Supports SMB Multichannel
  • 16GB of server-grade DDR5-4800 ECC memory (Max 64GB)
  • 2 x USB 4.0 (Type-C)
  • 3 x USB 3.2 Gen 2 (Type-A)
  • Suitable for 4K editing, enthusiasts, and content creation
ONLY WHILE STOCKS LAST!
Manufacturer Warranty: 3 Year
Manufacturer PN: FS6812X
Manufacturer Website

$2419

12 x m2 nvme slot asustor flashtor 12 pro gen2 10gb nas unit

Hardware Specifications

CPU

CPU Model AMD Ryzen V3C14
  CPU Architecture x64 64-bit
  CPU Frequency Quad-Core 2.3GHz (burst up 3.80 GHz)

Memory

Memory 16GB ECC DDR5-4800 SO-DIMM Compatibility
  Memory Module Pre-installed 16GB (1x 16GB)
  Total Memory Slots 2
  Memory Expandable up to 64GB
  • Support mixed capacity
  • Supports ECC memory
    • ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
Installation Guide
  Flash Memory 8GB eMMC

Storage

M.2 Drive Slots 12
  Compatible Drive Type Compatibility
  • M.2 2280 NVMe
  M.2 PCIe Interface
  • 1x PCIe 4.0 x4
  • 3x PCIe 4.0 x2
  • 4x PCIe 4.0 x1
  • 1x PCIe 3.0 x4
  • 1x PCIe 3.0 x2
  • 2x PCIe 3.0 x1
  Maximum Drive Bays with Expansion Unit 12

External Ports

Expansion 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A; 2 x USB 4.0 (40Gbps) Type-C
  • Note. USB 4.0 is backward compatible with 3.2 Gen2 (10Gbps max), USB 3.2 Gen1 (5Gbps) and 2.0
  • Note. The Lockerstor Gen3 and Flashstor Gen2 series are based on AMD's current USB4 driver. AMD USB4 at the moment only supports external storage devices and direct connection between another Lockerstor Gen3 or Flashstor Gen2 series NAS.
  Network 2 x 10 Gigabit Ethernet (10G/2.5G/1G/100M)



Multimedia Output N/A

Others

System Fan 1 x 80mm
  Power Supply Unit / Adapter 120W x1
  Input Power Voltage 100V to 240V AC
  Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
  Warranty 3 Years

Operation

Power Consumption 32.2 W (Operation);
2.8 W (Sleep Mode)
  Noise Level 18.6dB
  Operation Temperature 0°C~40°C (32°F~104°F)
  Storage Temperature -20°C~70°C (-4°F~158°F)
  Humidity 5% to 95% RH

Size and Weight

Size 48.3 (H) x 308.26 (W) x 193 (D) mm
  Weight 1.45 kg / 3.19 lb

Software & Features

General Specifications

Supported OS
  • Windows 10, 11, Server 2016, Server 2019, Server 2022
  • macOS
  • UNIX, Linux, and BSD
  Supported Languages Deutsch, English, Français, Italiano, Nederlands, ???????, ???, ??, ????, ????, Ceská, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ???????
  Supported Browsers
  • Firefox
  • Chrome
  • Safari
  • Microsoft Edge

Network

Network Protocols CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
  Connection and transmission
  • TCP/IP (IPv4 & IPv6)
  • Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover
  • Jumbo Frame (MTU)
  • VLAN
  • EZ Connect
  • Wireless Network
  • DDNS and EZ-RouterCompatibility

File Management & Sharing

File System
  • Internal Drive: EXT4 ,Btrfs
  • External Drive: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT ,Btrfs
  File Explorer
  • Web-based File Management
  • ISO File Mounting
  • Share Links
  • Task Monitor
  • Browse Files on Local PC
  • Thumbnail Previews
  • Data Access via External Optical Drive
  • Supports video playback
  Network Recycle Bin
  • Share folder-based
  • Maintains original directory structure and file permission
  • On-click restore
  • Supports scheduled emptying
  • Filtering rules
    1. File size
    2. File extension
  • Deletion Settings
    1. File size
    2. File date

Storage management

Supported RAID levels
  • Single
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  Supported RAID migration methods
  • Single to RAID 1
  • Single to RAID 5
  • Single to RAID 6
  • Single to RAID 10
  • RAID 1 to RAID 5
  • RAID 1 to RAID 6
  • RAID 1 to RAID 10
  • RAID 5 to RAID 6

M.2 Volume

RAID levels supporting storage expansion by complete drive replacement
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  RAID levels supporting storage expansion by drive addition
  • RAID 5
  • RAID 6
  • RAID 10
  RAID spare drive support
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
  iSCSI/IP-SAN
  • Maximum Targets: 256
  • Maximum LUNs: 256
  • Maximum Snapshot Versions of a Single LUN: 256
  • Target Masking
  • LUN Mapping
  • ISO File Mounting
  • Supports MPIO
  • Persistent (SCSI-3) Reservations
  Disk Management
  • Scheduled Bad Block Scans
  • Scheduled S.M.A.R.T Scans

Access & Security

Access Control
  • Maximum Number of Users: 4096
  • Maximum Number of Groups: 512
  • Maximum Number of Shared Folders: 512
  • Maximum Number of Concurrent Connections: 512
  • Supports Windows Active Directory
  • Supports Windows Active Directory / LDAP
  ACL
  • Provides both Windows ACL and Linux ACL permission configuration methods
  • Can enable Windows ACL for specific shared folders
  • Comprehensive support for Windows’ 13 types of advanced permission settings
  • Can view Windows ACL permission settings from within ADM
  • Supports local users and groups
  • Exclusive permission reset function allows users to quickly restore default permissions
  System Administration
  • Log Type: System Log, Connection Log, File Access Log
  • Real-time Online User Monitor
  • Real-time System Monitor
  • User Quota
  • Virtual Drive (ISO Mounting, Maximum 16)
  • UPS SupportCompatibility
  Security
  • AES 256-Bit Encryption
  • Firewall: Prevent Unauthorized Access
  • Alert Notifications: E-mail, SMS
  • Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
  • Built-in Hardware Encryption Engine: AS10/11/31/32/33/40/52/53/54/6/61/62/63/64/65/66/67/70/71/FS67 Series
  • RAID Scrubbing: detects the integrity and consistency of RAID 5 and RAID 6 drive data.
  Network Defender
  • Auto black list
  • Trusted list
  • Black/White list
    • Supports IP/IP range/geolocation

Backup

Backup Solutions
  • Rsync (Remote Sync) Backup
  • Cloud Backup
  • FTP Backup
  • External Backup
  • EZ Sync
  • SMB Backup
  Snapshots
  • Btrfs Snapshots
  • 256 Snapshots
  • iSCSI LUNs

Others

ASUSTOR Hightlight
  • System Migration
  • EZ Connect
  • Dr. ASUSTOR
  • 2-way Backup
  • Task Monitor
  Eco-Friendly Design
  • System Automatically Enters Sleep Mode (Schedule S3)
  • Auto-Standby for external drives
  • Auto Fan Control
  • LED Night Mode
  • Power Schedule: On, Off, Restart, and Sleep
  Energy Control
  • Configurable Disk Hibernation and Sleep Mode Wait Time
  • Configurable Time Period for Sleep Mode Activation
  • Automatic Sleep
