16 Port Gigabit Netgear GS116AU Network Switch
Web ID: 3582
High-speed, auto-switching 10/100/1000 Mbps Ethernet, Silently delivers up to 2000 Mbps on each port, Integrates 10, 100, & 1000 Mbps devices within a network, Honors Layer 2 802.1p traffic priority tags, Space-saving desktop dimensions.
Manufacturer Warranty: 5 Year
Manufacturer PN: GS116AU
GTIN: 606449034998
Manufacturer Website
Power up Your Small Network to Gigabit Speeds
- Delivers Gigabit speeds—up to 10x faster than Fast Ethernet
- Integrates 10/100/1000 Mbps devices on the same network
- Fits neatly into small workspaces–compact, metal case
- Runs silently without a fan
- Auto green mode detects cable length and adjusts power usage to save energy
Features
- Each port delivers up to 2000 Mbps of network speed (full duplex)
- Fast, auto-switching and auto-sensing 10/100/1000 Mbps Ethernet connection
- 16 switched ports provide bandwidth for PCs, servers or switches
- Auto Uplink™ automatically adjusts for straight-through or crossover cables
- Supports jumbo frames up to 16 KB
- Honors TOS/802.1p prioritization
NETGEAR Green
- Up to 43% lower power consumption **
- Auto power-down mode saves energy when port is unused
- Auto green mode detects cable length and adjusts power usage to save energy
- Packaging manufactured with at least 80% recycled materials
Ordering Part Number (United States) : GS116NA
Network Ports
- 16 auto-sensing 10/100/1000 Mbps UTP ports
Forwarding Mode
- Store-and-forward
Performance
- Bandwidth: 32 Gbps (non-blocking)
- Forward rate (10 Mbps port): 14,800 packets/sec
- Forward rate (100 Mbps port): 148,000 packets/sec
- Forward rate (1000 Mbps port): 1,488,000 packets/sec
- Latency (100 to 100 Mbps): 40 μ (max)
- Latency (1000 to 1000 Mbps): 10 μ (max)
- Queue buffer memory: 512 Kbytes per port
- MAC address database: 8,000
- Acoustic noise: 0 dB
- Heat dissipation: 38.8 Btu/hr
- Mean time between failures (MTBF): 393,000 hours (~45 years)
Power Consumption
- 12V DC, 1.5A, 18W; plug is localized to country of sale
Status LEDs
- Power, link, speed and activity
Physical Specifications
- Dimensions: (w x d x h) 285 x 103 x 27 mm (11.22 x 4.06 x 1.06 in)
- Weight: 1.08 kg (2.38 lb)
Environmental Specifications
- Operating temperature: 0º to 50º C (32º to 122° F)
- Operating humidity: 90% maximum relative humidity, non-condensing
Safety Agency Approvals
- CE mark, commercial
- UL listed (UL 1950)
- C-Tick
Electromagnetic Compliance
- CE Class A
- FCC Part 15 Class A
- EN 55022 (CISPR 22)
- EN 55024
- VCCI Class A
- C-Tick Class A
Standards Compliance
- IEEE 802.3i 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- Honors 802.1p priority tags
- Honors DSCP priority tags
- Jumbo frame support: up to 16 KB
System Requirements
- Category 5e cables or better
- Network card for each PC or server (e.g. NETGEAR GA311)
- Network software (e.g., Microsoft® Windows®, Linux®, Mac® OS)
Warranty
- Switch: NETGEAR Lifetime Warranty†
- Power adapter: NETGEAR 2-year Warranty
ProSupport™ Service Packs Available
OnCall 24x7
- PMB0331-100 (US)
- PMB0331 (non-US)
XPressHW
- PRR0331
Package Contents
- ProSafe 16-port Gigabit Desktop Switch (GS116v2)
- Wall-mount kit
- AC adapter
- Installation guide
- Warranty/support information card
NETGEAR Related Products
Accessories
- Gigabit Ethernet PCI Adapter (GA311)
- Gigabit PC Card Adapter (GA511)
Switches
- ProSafe 5-port Gigabit Desktop Switch (GS105)
- ProSafe 8-port Gigabit Desktop Switch (GS108)
Ordering Information
- North America: GS116NA
- Europe - General: GS116GE
- Europe - UK: GS116UK
- Asia: GS116AU
- Japan: GS116JP
