6 x M.2 NVMe Slot Asustor FLASHTOR 6 Gen2 10Gb NAS Unit
Web ID: 45304
- AMD Quad-Core 6 nm Ryzen Embedded V3C14 Processor
- Six M.2 slots for NVMe SSDs, Supports up to PCIe 4.0 x4
- 10-Gigabit Ethernet
- Powered by 8 GB of DDR5-4800 RAM ECC RAM supported
- 2 x USB 4.0 (Type-C)
- 3 x USB 3.2 Gen 2 (Type-A)
- Suitable for 4K editing, enthusiasts, and content creation
Manufacturer Warranty: 3 Year
Manufacturer PN: FS6806X
Manufacturer Website
$1729
Hardware Specifications |
||
---|---|---|
CPU |
CPU Model | AMD Ryzen V3C14 |
CPU Architecture | x64 64-bit | |
CPU Frequency | Quad-Core 2.3GHz (burst up 3.80 GHz) | |
Memory |
Memory | 8GB DDR5-4800 SO-DIMM Compatibility |
Memory Module Pre-installed | 8GB (1x 8GB) | |
Total Memory Slots | 2 | |
Memory Expandable up to | 64GB
|
|
Flash Memory | 8GB eMMC | |
Storage |
M.2 Drive Slots | 6 |
Compatible Drive Type Compatibility |
|
|
M.2 PCIe Interface |
|
|
Maximum Drive Bays with Expansion Unit | 12 | |
External Ports |
Expansion | 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A; 2 x USB 4.0 (40Gbps) Type-C
|
Network | 1 x 10 Gigabit Ethernet (10G/2.5G/1G/100M) | |
|
Multimedia Output | N/A |
Others |
System Fan | 1 x 80mm |
Power Supply Unit / Adapter | 90W x1 | |
Input Power Voltage | 100V to 240V AC | |
Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA | |
Warranty | 3 Years | |
Operation |
Power Consumption | 17.9 W (Operation); 1.2 W (Sleep Mode) |
Noise Level | 18.6dB | |
Operation Temperature | 0°C~40°C (32°F~104°F) | |
Storage Temperature | -20°C~70°C (-4°F~158°F) | |
Humidity | 5% to 95% RH | |
Size and Weight |
Size | 48.3 (H) x 308.26 (W) x 193 (D) mm |
Weight | 1.4 kg / 3.08 lb |
Software & Features |
||
---|---|---|
General Specifications |
Supported OS |
|
Supported Languages | Deutsch, English, Français, Italiano, Nederlands, ???????, ???, ??, ????, ????, Ceská, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ??????? | |
Supported Browsers |
|
|
Network |
Network Protocols | CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog |
Connection and transmission |
|
|
File Management & Sharing |
File System |
|
File Explorer |
|
|
Network Recycle Bin |
|
|
Storage management |
Supported RAID levels |
|
Supported RAID migration methods |
|
|
M.2 Volume |
RAID levels supporting storage expansion by complete drive replacement |
|
RAID levels supporting storage expansion by drive addition |
|
|
RAID spare drive support |
|
|
iSCSI/IP-SAN |
|
|
Disk Management |
|
|
Access & Security |
Access Control |
|
ACL |
|
|
System Administration |
|
|
Security |
|
|
Network Defender |
|
|
Backup |
Backup Solutions |
|
Snapshots |
|
|
Others |
ASUSTOR Hightlight |
|
Eco-Friendly Design |
|
|
Energy Control |
|
Featured Apps |
||
---|---|---|
Official ASUSTOR Apps |
Antivirus (ClamAV) |
|
Download Center |
|
|
Cloud Backup Center |
|
|
DataSync Center |
|
|
FTP Explorer |
|
|
HiDrive |
|
|
LooksGood |
|
|
Mail Server |
|
|
Photo Gallery 3 |
|
|
Surveillance Center Compatibility |
|
|
SoundsGood |
|
|
Takeasy |
|
|
UPnP Media Server |
|
|
VPN Client |
|
|
VPN Server |
|
|
RADIUS Server |
|
|
SNMP Server |
|
|
Syslog server |
|
