ASUS NUC 12 Pro i5-1250P vPro Barebone Mini PC RNUC12WSHV50001
Web ID: 45214
Barebone Chassis Requires: RAM, SSD, Windows.
CPU: Intel i5-1250PCPU Cores: 12 Core || 16 Thread || Up to 4.4GHz || 12MB Cache
RAM: 2 x SODIMM DDR5
Storage Interface: M.2 PCIe || SATA
GPU: Integrated Graphics || Intel Iris Xe iGPU
Video Interface: 2 x Thunderbolt 4 || 2 x HDMI
USB: 4 x USB Type-A
Connectivity: Wireless-AXE | BT 5.3 | 2.5 Gb
, BONUS 0.5m ALOGIC Aus 3 Pin Clover Wall to IEC C5 Male to Female PN MF-AUS3PC5-0.5 ONLY WHILE STOCKS LAST!
Manufacturer Warranty: 1 Year
Manufacturer PN: RNUC12WSHV50001
Manufacturer Website
$599
| Model | ASUS NUC 12 Pro Kit |
| Operating System | Needs Operating System |
| CPU | Intel® Core™ i5-1250P Processor, vPro Support |
| Chipset | Integrated |
| Graphics | Intel® Iris® Xe Graphics |
| Memory | System requires dual-channel memory configuration for optimal performance |
| 2 x SO-DIMM, Up to DDR4-3200, 32GB2 | |
| Storage | 1 x M.2 2280 PCIe Gen4x4, supports 128GB8TB NVMe™ SSD |
| 1 x SATA Power/DATA header for 2.5in SSD/HDD, supports 128GB~2TB SATA drive (Tall SKU only) | |
| Wireless Data Network | Intel® Wi-Fi 6E AX211 (Gig+), Bluetooth 5.3 |
| Intel® vPro® Technology (i7/i5 vPro SKUs only) | |
| LAN | Intel® Ethernet Controller I226-V/LM, 2.5G |
| *Intel® Ethernet Controller I226-LM included on vPro enabled systems | |
| Audio | Realtek ALC269 |
| Front(Side) I/O Ports | 2 x USB 3.2 Gen2 Type-A |
| 1 x 3.5mm Headset Jack | |
| 1 x Kensington Lock | |
| Back I/O Ports | 2 x Thunderbolt 4 Type-C w/ DisplayPort 1.4 |
| 1 x USB 3.2 Gen 2 Type-A | |
| 1 x USB 2.0 Type-A | |
| 2 x HDMI 2.1 (TMDS) | |
| 1 x RJ45 LAN | |
| 1 x DC-in | |
| Power Supply | 20VDC, 6.0A, 120W Power Adapter |
| Dimensions (W x D x H) | Tall Chassis: 117 x 112 x 54 mm |
| Weight | NUC13ANH: 610g |
| ID | Black, With ASUS LOGO |
| Accessories | AC Adapter+Power Cord* |
| VESA Bracket and Screws | |
| M3 Screws for 2.5in Drive (Tall Chassis Only) | |
| Cable Clip | |
| Safety/Caution/Regulatory Insert | |
| Warranty Card | |
| *Power cord included is region specific, and some SKUs do not include the power cord |
