Canon imageFORMULA DR-C225II USB Document Scanner

Canon imageFORMULA DR-C225II USB Document Scanner

Web ID: 13835

With the use of a U-turn path, there is no need to leave a space in front of the scanner for document delivery, resulting in a neat, slim body for space-saving operation.The imageFORMULA DR-C225 allows high-speed scanning of 25 ppm* in either colour or back and white and the document feed can handle many different types of documents ONLY WHILE STOCKS LAST!
Manufacturer Warranty: 1 Year
Manufacturer PN: DR-C225II
GTIN: 4528472106656
Manufacturer Website

$599

Add to cart

Out of Stock

Compare

Wish List

Question

A Full Range of Powerful Functions

A slim body that saves space
Once a document is fed in, it follows a U-turn path and is discharged at the front section of the main unit. This eliminates the need to leave space in front for document delivery and results in outstanding space-saving. Also, switching to straight ejection path makes it possible to scan cards and other thick documents.

Handy face-up feeding
When scanning, users can orient the document the right way up with the printed side facing them. This is also how it will appear on the display screen, thus making it easy to confirm the order of multiple sheets for increased scanning efficiency.

High-speed scanning in a compact package

Reliable double feed detection
As documents are fed in, the upper sensor transmits ultrasonic waves that are received by the lower sensor. If multiple feeding should occur, document feeding is automatically halted and a double feed is indicated, so there is no risk of data loss during scanning

Various Image Processing Options

Full auto mode
Character emphasis
Skip blank page
Auto colour detection
Advanced text enhancement
Auto size detection
Deskew
Folio

DR-C225/DR-C225W Technical Specifications

Type

Desktop sheet-fed scanner

Scanning document size

Plain Paper: U-turn path

Width: 50.8 to 216 mm (2” to 8.5”)

Length: 70 to 356 mm (2.76” to 14”)

Plain Paper: Straight path

Width: 50.8 to 216 mm (2” to 8.5”)

Length: 53.9 to 356 mm (2.12” to 14”)

Use Long Document mode to scan documents up to 3,000 mm (118.1”) long.

Business Card

50 x 53.9 mm (1.97” x 2.12”) or larger Vertical feeding only.

Plastic Card

53.9 x 85.5 mm (2.12” x 3.37”) (ISO standard) Embossed cards can be scanned.

Scanning document thickness

Plain Paper: U-turn path

53 to 128 g/m (*2)

(0.06 to 0.15 mm)

Plain Paper: Straight path

40 to 209 g/m (*2)

(0.05 to 0.25 mm)

Business Card

300 g/m2 (140 lb bond)

0.35 mm (0.0138”) or less

Plastic Card

0.76 mm (0.03”) or less

Document feeding

Automatic

Light source

LED

Scanning side

Simplex / duplex, skip blank page, folio

Scanning modes

Black and white, Error diffusion, Advanced Text Enhancement, Advanced Text Enhancement II (for Windows only), 256-level grayscale, 24-bit colour

Scanning resolution

151 x 150 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi

Scanning speed (*1)

Simplex

26 ppm

Duplex

50 ipm

Interface

Hi-Speed USB 2.0

Software

Windows

ISIS/TWAIN driver, CaptureOnTouch, Presto! BizCard, Omnipage, PaperPort, eCopy PDF Pro Office, Evernote (*2)

Mac(*3)

TWAIN driver, CaptureOnTouch, Presto! BizCard, Presto! PageManager, Evernote (*2)

External dimensions (W x D x H)

301 mm (11.81”) x 220 mm (8.66”) x 156 mm (6.14”)

Weight

DR-C225

Approx. 2.7 kg

DR-C225W

Approx. 2.8 kg

Power requirements

AC100 to 240 V (50/60Hz)

Power consumption

DR-C225

Scanning: 12.7 W or less (120V), 12.8 W or less (200V)

Sleep: 1.7 W or less (120V), 1.8 W or less (200V), OFF: 0.5 W or less

DR-C225W

Scanning: 15.6 W or less 4.3 W or less (120V)

Sleep: 4.4 W or less (200V), OFF: 0.5 W or less

Operating environment

Temperature

10°C to 32.5°C (50°F to 90.5°F)

Humidity

20% to 80% RH

Options / Consumables

Flatbed Scanner Unit 101/201(DR-C225 only), Exchange Roller Kit (feed roller and retard roller)

Basic wireless LAN specifications for DR-C225W

Wireless Standard

IEEE802.11b/g/n (2.4 GHz only)

Frequency

2.4 GHz band

Transfer Method

IEEE802.11b: DS-SS system, IEEE802.11g: OFDM system

Data Rate (*4)

IEEE802.11n: MIMO-OFDM system IEEE802.11b: Up to 11 Mbps, IEEE802.11g: Up to 54 Mbps IEEE802.11n: Up to 300 Mbps

Security

WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)

Easy Setting

WEP (64/128 bit)

Connection Modes

WPS

imageFORMULA DR-C225/DR-C225W

*1 Actual scanning speed may vary depending on your system configuration and PC.

*2 Installed via Internet connection.

*3 Requires Mac OS X 10.4.11 or later.

*4 Varies according to environmental conditions.

Specifications are subject to change without notice.
