Netgear EAX15 AX1800 WiFi Mesh Extender

Physical Specification

• AX1800 WiFi Mesh Extender (EAX15) : Dimensions 5.9 x 2.7 x 2.1in (149 x 68.4 x 52.3mm), Weight 0.49lb (222g)

Technical Specs

• WiFi Technology : 802.11ax
• WiFi Performance : AX1800
• Ports : One (1) 10/100/1000 Ethernet port with auto-sensing technology
• WiFi 6 Features : Gigabit Internet speeds throughout the home*, 1.5X Better Performance than a Wi-Fi 5 (802.11ac) Extender—4 Stream WiFi with up to 0.6+1.2 Gbps† for fast wireless speeds**, More WiFi for More Devices— OFDMA allows efficient data transmission up to 4 devices at the same time§. Uplink OFDMA improves scheduling during high volumes of upload traffic, Up to 4 Simultaneous WiFi Streams—4-stream MU-MIMO‡ enables up to four (4) 1x1 devices to stream content at the same time
• Security : Standards-based WiFi Security (802.11i, 128-bit AES encryption with PSK)
• Ease of Use : Wi-Fi 6 Supports All Current WiFi Devices—Backward compatible with Wi-Fi 5, Wi-Fi 4 and earlier generation WiFi devices, Push & Connect using WPS
• System Requirements : 2.4 and/or 5GHz 802.11 a/b/g/n/ac/ax WiFi router or gateway. Microsoft^® Internet Explorer^® 8.0, Firefox^® 20 or Safari^® 5.1 or Google Chrome^® 25.0 browsers or higher

Support & Warranty

• Warranty : Warranty:This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller.
• Support : Support: Extend your warranty & technical support within 90 days of product purchase [US only]. Visit: prosupport.netgear.com/home.
• Support
• Footnotes : † Maximum wireless signal rate derived from IEEE 802.11specifications. Actual data throughput and wireless coverage will vary and be lowered by network and environmental conditions, including network traffic volume, device limitations, and building construction. NETGEAR makes no representations or warranties about this product’s compatibility with future standards. Up to 1,800Mbps wireless speeds achieved when connecting to other 802.11ax 1,800 Mbps devices.
• ‡As compared to an AC1200 2x2 router
• § Requires compatible AX clients with DL-OFDMA and UL-OFDMA support
• * Gigabit Internet speeds require compatible service plans and equipment
• **When working with 160MHz clients as compared to a 2x2 AC router that does not support 160MHz
• ***Requires client device that supports 160MHz bandwidth on WiFi

What's in the box

• AX1800 4-Stream WiFi Mesh Extender (EAX15v2)
• Quick start guide
