Noctua NH-D12L Chromax Black Multi Socket CPU Cooler
Web ID: 39787
The NH-D12L chromax.black is an all-black version of Noctuas award-winning NH-D12L low-height 120mm class CPU cooler that has been conceived to combine outstanding quiet cooling performance with superior case compatibility. At a height of only 145mm (13mm lower than Noctuas regular 120mm models), it fits many 4U enclosures as well as narrower tower cases that have been previously limited to solutions with 92mm fans. At the same time, its five heatpipe dual-tower design and state-of-the-art NF-A12x25r 120mm fan allow it to achieve a level of efficiency that surpasses many full-height 120mm models. Thanks to its single-fan configuration and asymmetrical fin stacks, the NH-D12L provides 100% RAM compatibility on AMD AM5/AM4 and Intel LGA1851/1700/1200 by staying clear of the memory slots.
ONLY WHILE STOCKS LAST!
Manufacturer Warranty: 6 Year
Manufacturer PN: NH-D12L-CH-BK
Manufacturer Website
Product Details
Notes and warnings
Further reading:
Which Noctua 120mm CPU cooler should I choose? How do the NH-U12A, NH-D12L, NH-U12S and NH-U12S redux compare against each other?
Cooler Specification
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4
Height (without fan)
145 mm
Width (without fan)
125 mm
Depth (without fan)
113 mm
Weight (without fan)
700 g
Height (with fan)
145 mm
Width (with fan)
125 mm
Depth (with fan)
113 mm
Weight (with fan)
890 g
Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
148
Max. TDP
see NSPR
Fan compatibility
NF-A12x25r (square-frame 120mm fans not supported)
Scope of delivery
- Black NH-D12L heatsink
- NF-A12x25r PWM chromax.black premium fan
- NA-RC14 Low-Noise Adaptor (L.N.A)
- NT-H1 high-grade thermal compound
- Black SecuFirm2™ mounting kit
- Noctua metal case-badge
6 Years
FAN Specification
Model
Noctua NF-A12x25r PWM chromax.black
Bearing
Max. rotational speed (+/- 10%)
2000 RPM
Max. rotational speed with L.N.A. (+/- 10%)
1700 RPM
Min. rotational speed @ 20% PWM (+/-20%)
450 RPM
102,1 m³/h
84,5 m³/h
Max. acoustical noise
22,6 dB(A)
Max. acoustical noise with L.N.A.
18,8 dB(A)
102.1 m³/h
84.5 m³/h
Acoustical noise
22.6 dB(A)
Input power (typical)
1.2 W
Input power (max.)
1.68 W
Voltage range
12 V
MTTF
> 150.000 h
