Noctua NH-U12A-CH-BK Multi Socket CPU Cooler - Chromax Black

Web ID: 34737

The NH-U12A is the latest, 5th generation of Noctua's award-winning NH-U12 series of 120mm size premium-quality quiet CPU coolers. Conceived to push the envelope of the 120mm form factor, it combines two of Noctua's flagship model NF-A12x25 PWM 120mm fans with a completely redesigned heatsink featuring 7 heatpipes and an increased fin surface area for superior heat dissipation. This way, the NH-U12A can rival the performance of many 140mm size coolers while offering 120mm class case and PCIe compatibility. Topped off with the trusted, pro-grade SecuFirm2 multi-socket mounting system, the NH-U12A is a deluxe choice that combines top-tier performance with excellent compatibility and outstanding quietness of operation.
Manufacturer Warranty: 6 Year
Manufacturer PN: NH-U12A-CH-BK
GTIN: 841501100246
Manufacturer Website

$239

noctua nh-u12a-ch-bk multi socket cpu cooler - chromax black

Cooler Specification

Socket compatibility



Intel LGA1700, LGA1200, LGA1150, LGA1151, LGA1155, LGA1156, LGA2011, LGA2066 & AMD AM4, AM5

Height (without fan)



158 mm

Width (without fan)



125 mm

Depth (without fan)



58 mm

Weight (without fan)



760 g

Height (with fan)



158 mm

Width (with fan)



125 mm

Depth (with fan)



112 mm

Weight (with fan)



1220 g

Material



Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR



169

Max. TDP



see NSPR

Fan compatibility



120x120x25

Scope of delivery



  • Black NH-U12A heatsink
  • 2x NF-A12x25 PWM chromax.black premium fan
  • 2x NA-RC14 Low-Noise Adaptor (L.N.A)
  • NA-YC1 4-pin PWM y-cable
  • NT-H1 high-grade thermal compound
  • Black SecuFirm2™ mounting kit
  • Noctua Metal Case-Badge

Warranty



6 Years

FAN Specification

Model



Noctua NF-A12x25 PWM chromax.black

Bearing



SSO2

Max. rotational speed (+/- 10%)



2000 RPM

Max. rotational speed with L.N.A. (+/- 10%)



1700 RPM

Min. rotational speed @ 20% PWM (+/-20%)



450 RPM

Max. airflow



102,1 m³/h

Max. airflow with L.N.A.



84,5 m³/h

Max. acoustical noise



22,6 dB(A)

Max. acoustical noise with L.N.A.



18,8 dB(A)

Voltage range



12 V

MTTF



> 150.000 h
