SilverStone RM41-506 Black 4U Rackmount Case No PSU

Web ID: 32950

Supports up to SSI-CEB motherboard
Supports Standard profile PCI / PCIe x 7 slots
Six 5.25" drive bays for flexible 5.25" device installation
5Gbps Super Speed USB 3.1 Gen 1 interface, backward compatible with USB 2.0 / 1.1
Mounting holes ready for quick rail slide installation (rail slide sold separately) ONLY WHILE STOCKS LAST!
Manufacturer Warranty: 1 Year
Manufacturer PN: SST-RM41-506
GTIN: 844761019228
Manufacturer Website

$289

silverstone rm41-506 black 4u rackmount case

SPECIFICATIONS

Model No. SST-RM41-506
Chassis form factor 4U
Material SGCC
Motherboard CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7")
Drive Bay External 5.25" drive bay x 6
Internal 4 x 3.5"
2 x 2.5” (up to 15mm)
1 x 2.5” (up to 15mm) or slim optical (12.7mm)
Cooling System Front 80 x 25mm fan x 1(fan not included)
Rear 80 x 25mm fan x 2
Power Supply PS2 / ATX / Mini Redundant (supports up to 160mm)
Expansion card Length w/ 5.25” drive cage: 278mm
Length w/o 5.25” drive cage: 426mm
Limitation of CPU cooler 148mm
Expansion Slot Standard profile PCI / PCIe x 7
Front I/O Port USB 3.1 Gen1 Type-A x 2
Front buttons Power On / Off, system reset
Indicators Power status x 1, HDD activity x 1, LAN activity x 2
Main metal thickness 1.2mm
Net Weight 9.7 kg
Dimension 430mm (W) x 176mm (H) x 446mm (D)
16.93" (W) x 6.93" (H) x 17.56" (D)
  * The RM41-506 has two rows of mounting holes for sliding rails. If you wish to align RM41-506 in one whole U position as opposed to leaving half U height top and bottom, please secure rails to the bottom row of mounting holes.
