Yealink (W76P) Wireless DECT Solution including W70B Base Station and 1x W56H Handset - W76P

Phone Features

• Up to 20 simultaneous calls

• Up to 10 handsets

• Up to 10 VoIP accounts

• Up to 2 simultaneous calls per handset

• Up to 6 repeaters per base station (RT30)

• Handset selection for receiving call

• Handset and number selection for placing call

• Paging, intercom, auto answer, dial plan

• Call hold, call transfer, 3-way conference

• Switching between calls

• Call waiting, mute, silence, DND

• Caller ID with name and number

• Anonymous call/Anonymous call rejection

• Call forward: Always/Busy/No Answer

• Speed dial/Voicemail/Redial

• Message Waiting Indication (MWI)

• Music on hold (server-based)

• Local phonebook for up to 1000 entries (store in the base)

• Remote phonebook/LDAP/XML phonebook

• Phonebook search/import/export

• 100 call history per handset: All/Placed/Missed/ Received/Forward

• Direct IP call without SIP proxy

• Reset to factory, reboot

• Keypad lock, emergency call

• Broadsoft directory, BroadSoft call log

• Broadworks feature key synchronization

• Shared Call Appearance (SCA)

• XML browser

• Action URI

Personalization

• 9 ringer melodies

• Screen saver

• Multilingual user interface

Management

• Auto-provision via TFTP/FTP/HTTP/HTTPS/RPS

• Auto-provision with PnP

• Handset upgrade: OTA (Over-The-Air)

• Configuration: browser/phone/auto-provision

• Trace package and system log export

Audio Features

• Full-duplex speakerphone

• Hearing Aid Compatibility (HAC) compliant

• Receiver volume control: 5 steps

• Ringer volume control: 5 steps+off

• Multiple advisory tones

• Acoustic warning for low battery status

• DTMF • Wideband codec: Opus, AMR-WB (optional), G.722

• Narrowband codec: AMR-NB (optional), PCMU,PCMA, G.726, G.729, G.729A, iLBC • VAD, CNG, AGC, PLC, AJB • AEC (supported by W56H)

• Support VQ-RTCPXR (RFC6035), RTCP-XR

Network Features

• SIP v1 (RFC2543), v2 (RFC3261)

• SNTP/NTP

• VLAN (802.1Q and 802.1P)

• 802.1x, LLDP

• STUN Client (NAT Traversal)

• UDP/TCP/TLS

• IP assignment: Static/DHCP

• Support outbound proxy server backup

Security

• Open VPN

• Transport Layer Security (TLS)

• HTTPS (server/client), SRTP (RFC3711)

• Digest authentication

• Secure configuration file via AES encryption

• Support SHA256/SHA512/SHA384

• Three-level configuration mode: Admin/Var/User

DECT

• Frequency bands: 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US), 1902 – 1906 MHz (TH), 1910 – 1920 MHz (BR)

Interface

• 1 x RJ45 10/100M Ethernet port

• Power over Ethernet (IEEE 802.3af), Class 1

• Headset jack (3.5 mm)

Physical Features

• Indoor Range: 50m (in ideal conditions)

• Outdoor Range: 300m (in ideal conditions)

• Standby Time: 400 hours (in ideal conditions)

• Talk Time: 30 hours

• 2.4’’ 240x320 pixels color display

• Desktop or wall mountable

• LCD backlit, key backlit

• Energy-saving ECO mode/ECO Mode+

• 12 key numerical keypad, 5 navigation keys, 2 softkeys, 6 function keys, 6 shortcut keys

• Three LED indicators on W70B: - 1 x Registration LED - 1 x Network Status LED - 1 x Power Indicator LED

• External Yealink AC adapter: AC 100-240V Input and DC 5V/600mA Output

• Color: Handset: Alabaster Silver ; Base: Classic Grey

• Handset size: 175mm x 53mm x 20.3mm

• Base station size: 130mm x 100mm x 25.1mm

• Operating humidity: 10 ~ 95%

• Operating temperature: 0~+40°C (+32~104°F)

Package Features

• Package contents: - W56H Handset - W70B Base Station - Base Stand - USB Charger Cradle - Two Power Adapters - Ethernet Cable - Belt Clip - Rechargeable Battery - Quick Start Guide

• Qty/CNT: 10 PCS

• Giftbox size: 205mm × 196mm × 95mm

• Carton meas: 495mm × 406mm × 223mm

• N.W: 7.5 kg

• G.W: 8.3 kg
